LED video wall upgrade kit Barco's LED video wall technology refresh program
To bring your control room visualization technology to the most recent high-quality standards, Barco now offers an all-in-one technology refresh program for its legacy video wall systems.
The video wall upgrade kit enables customers to upgrade from Barco's lamp-based OV-D2 (DLP), D1 (DLP) and p-Si (polysilicon LCD) video walls to its new LED-powered video walls.
A cost-effective migration path
Barco's LED-lit rear-projection video walls offer an unequalled visual experience in a wide range of 24/7 applications. Equipped with a unique liquid cooling system, the new video walls have a LED lifetime of up to 80,000 hours and a brightness level that is 20% higher than any other LED video wall on the market. Barco's Sense6 auto-calibration technology guarantees uniform colors and consistent brightness over time and across the display, eliminating the need for manual interventions.
With this video wall upgrade program, Barco offers a cost-effective migration path for current and legacy video wall installations - even installations dating from the late nineties. Please consult your Barco representative for more information on how to upgrade to Barco's LED-lit projection system.
The video wall upgrade kit includes:
- New LED-based projection engine
- New illumination unit with input box and cooling unit
- New mounting brackets & sheet metal
- Technology assessment for video wall controller upgrade
The new LED-based projection model and illumination unit can be seamlessly integrated into your existing mechanical structures. The upgrade can be performed without dismantling the side claddings, so dust intrusion is reduced to a minimum.
Features
Why upgrade?
- Safeguard your Barco investment for the future
- Benefit from 80,000 hours of LED lifetime
- Enjoy the brightest picture and the warmest colors
- Rely on a liquid-cooled LED system for 24/7 reliability
- Benefit from a lower cost of ownership
- Leave a small footprint with eco-friendly LED light sources
This product is an option of the following products
67" Display Wall system integrating 3-panel Poly-Silicon LCD technology with XGA resolution. Article number: R9631104 50" Display Wall system integrating 3-panel Poly-Silicon LCD technology with XGA resolution. Article number: RSPSI31440 80" XGA DLP™ projection module Article number: R9842906 67" dual lamp video wall system integrating DLP™ technology with XGA resolution. Article number: R9841830 50" dual lamp video wall system integrating DLP™ technology with SXGA resolution. Article number: R9842491,RSDLP32720 70" SXGA+ DLP™ projection module Article number: R9842903 50" dual lamp video wall system integrating DLP™ technology with SXGA+ resolution. 67" dual lamp video wall system integrating DLP™ technology with SXGA resolution. 84" Display Wall system integrating 3-panel Poly-Silicon LCD technology with SXGA resolution. Article number: R9831130 80" dual lamp video wall system integrating DLP™ technology with XGA resolution. Article number: R9842510 80" SXGA+ DLP™ projection module Article number: R9842907 Entry level 50" single lamp video wall system integrating DLP™ technology with XGA resolution Article number: R9842812 50" dual lamp video wall system integrating DLP™ technology with XGA resolution. 50" SXGA DLP™ projection module Article number: R9842982 Atlas67.C4DLP 84" Display Wall system integrating 3-panel Poly-Silicon LCD technologie with XGA resolution. Article number: R9831120 50" XGA DLP™ projection module Article number: R9842980 67" Display Wall system integrating 3-panel Poly-Silicon LCD technology with SXGA resolution. Article number: R9831110 70" SXGA DLP™ projection module Article number: R9842902 80" dual lamp video wall system integrating DLP™ technology with SXGA+ resolution. Article number: R9852830 70" XGA DLP™ projection module Article number: R9842901 Entry level 70" single lamp video wall system integrating DLP™ technology with XGA resolution Article number: R9842813 50" SXGA+ DLP™ projection module Article number: R9842981 67" dual lamp video wall system integrating DLP™ technology with SXGA+ resolution.
OverView cPG67 (Atlas C4)
OverView mP50
OV-808
OverView cDG67-DL
OverView mDR50-DL
OV-715
OverView mDR+50-DL
OverView cDR67-DL
OverView cPR84 (Atlas CS4)
OverView cDG80-DL
OV-815
OV-501
OverView mDG50-DL
OV-513
Atlas67.C4DLP
OverView cPG84 (Atlas C4)
OV-508
OverView cPR67 (Atlas CS4)
OV-713
OverView cDR+80-DL
OV-708
OV-701
OV-515
OverView cDR+67-DL
Upgrade path
| Screen size | Type | Order Number |
|---|---|---|
| 50” | Upgrade mDG -> OVL-508 | R98457005 |
| 50” | Upgrade mDG -> OVL-515 | R9845700 |
| 50” | Upgrade mDR -> OVL-513 | R9845800 |
| 50” | Upgrade mP -> OVL-508 | R98459005 |
| 50” | Upgrade mP -> OVL-515 | R9845900 |
| 50” | Upgrade OV-508 -> OVL-515 | R9846000 |
| 50” | Upgrade OV-513 -> OVL-513 | R9846100 |
| 50” | Upgrade OV-508 -> OVL-508 | R98460005 |
| 50” | Upgrade OV-515 -> OVL-515 | R9846200 |
| 70” | Upgrade cDG -> OVL-6708 | R98463005 |
| 70” | Upgrade cDG -> OVL-6715 | R9846300 |
| 70” | Upgrade cDR -> OVL-6713 | R9846400 |
| 70” | Upgrade cPG -> OVL-6708 | R98465005 |
| 70” | Upgrade cPG -> OVL-6715 | R9846500 |
| 70” | Upgrade cPR -> OVL-6713 | R9846600 |
| 70” | Upgrade OV-6715 -> OVL-6715 | R9846700 |
| 70” | Upgrade OV-6713 -> OVL-6713 | R9846800 |
| 70” | Upgrade OV-708 -> OVL-708 | R98469005 |
| 70” | Upgrade OV-708 -> OVL-715 | R9846900 |
| 70” | Upgrade OV-713 -> OVL-713 | R9847000 |
| 70” | Upgrade OV-715 -> OVL-715 | R9847100 |
| 80” | Upgrade cDG -> OVL-808 | R98472005 |
| 80” | Upgrade cDG -> OVL-815 | R9847200 |
| 80” | Upgrade OV-808 -> OVL-808 | R98473005 |
| 80” | Upgrade OV-815 -> OVL-815 | R9847300 |
| 80” | Upgrade cPG -> OVL-8408 | R98474005 |
| 80” | Upgrade cPG -> OVL-8415 | R9847400 |
| 80” | Upgrade cPR -> OVL-8413 | R9847500 |
| 100” | Upgrade OV-1015 -> OVL-1015 | R9847600 |
