Specyfikacja techniczna:

Brightness

• 6,125 (ISO)
• 5,400 (Center)
• 5,400 (ANSI)

Color wheel

• 4 Segment (RGBY) - 2X or 3X speed

Contrast (nominal)

• Full On/Off (Christie Real Black Enabled): 4,000,000:1
• Dynamic Contrast: 6,000:1
• Full On/Off (Christie Real Black Disabled): 1,200:1
• ANSI: 250:1

Display

• 1 x 0.65” DMD S600HB

Resolution

• 1920 x 1080 (2,073,600 pixels) 16:9

Illumination type

• High Efficiency Blue Laser Phosphor

Illumination lifetime

• 20,000 hours

Signal inputs

Standard

• HDMI x 2
• DVI-D x 1 (Digital only)
• HD15 x 1
• REMOTE IN: 3.5mm stereo female (Provides serial communications and power.)
• HDBaseT (RJ45 x 1)
• RJ45 x 1 (Control over wired network connection)

3D

• HDMI 1.4, HDBaseT - Frame Packed, Top/Bottom, Side By Side
• Up to 120Hz output
• (Does not support Frame Sequential 3D)
• 3D Sync Out (BNC) - for genlocking projectors or controlling emitters

Signals

• HDTV formats VGA through to WUXGA (1920 x 1200)
• Horizontal and vertical scaling while maintaining aspect ratio, all inputs

Pixel clock

• 162MHz

Scan rates

• Horizontal: 15 kHz to 91 kHz
• Vertical: 24 Hz to 120 Hz

Signal outputs

• HD15 x 1

Control & networking

• RS232 In
• Control via HDBaseT
• Ethernet (10/100) RJ45
• Built-in Backlit Keypad
• Wired Remote Control (3.5mm stereo)

Accessories

Standard

• IR Remote w/ wired remote jack (wire not included)
• AC Line cords for projector
• User Manual

Optional

• Christie One Mount
• One Mount Extender Rod
• One Mount Rigging Kit (used with One Mount, One Mount Plus and/or One Mount Extender Rod)
• Cable Cover GS White

Lens mount

• Boresight adjustable
• Motorized horizontal and vertical lens offset
• Motorized zoom and focus adjustment

Lens options

• Lens 0.75-0.95 Zoom G/GS
• Lens 0.95-1.22 Zoom G/GS
• Lens Zm Std G/599-GS 1.22-1.53 (Lowest cost for G/555/599/630/635-GS)
• Lens Zoom HP G/GS 1.22-1.52 (All G & GS)
• Lens 1.52-2.89 Zoom G/GS
• Lens 2.9-5.50:1 Zoom G/GS
• Lens UST 0.36 (120"), Ultra short throw lens, 630/635/700/850/1075-GS

Lens offsets (max)

• +/- 100% Vertical (+/- 600 px)
• +/- 30% Horizontal (+/- 288 px)

Power requirements

Operating voltage

• Normal: 100-240 VAC @ 50/60 Hz (w/ 15A fuse)

Power consumption

• Normal Mode: 650W

Operating current

• Normal Mode: 9.5A (100V-240V)

Dissipation

• 97.5W

Audible Noise (typical 2x Wheel Speed)

• 34dB(A) Eco2 Mode
• 36dB(A) Normal Mode

Physical dimensions

(L x W x H)

• 19.90 x 17.95 x 7.6"
• 505 x 456 x 190mm w/o feet or lens

Physical weight

• 34.94 lb (15.85 kg) w/o lens

Shipping dimensions

(L x W x H)

• 24.65 x 23.43 x 13.74"
• 626 x 596 x 349mm

Shipping weight

• 47.06 lb (21.35 kg)

Operating environment

• 0 to 40° C (32 to 104° F), 0-2500 ft altitude
• 0 to 30° C (32 to 86° F), 5,000-10,000 ft altitude
• Humidity: 0 - 85% non-condensing

Regulatory

• Contact Christie for timing of certifications: UL/CSA/IEC 60950-1, FCC Class A, CE, FDA, CCC, KC, PSE, CU, SABS, BIS, VCCI, RCM, Ukr, TER, SASO
• This product conforms to all relevant European directives, standards, safety, health and environmental concerns
• RoHS, REACH, WEEE

Limited warranty

• 3 years parts and labor on the projector
• 3 years or 15,000 hours parts and labor on the illumination system*
• Contact an authorized Christie representative for full details of our limited warranty

*Please reference the Christie Standard Limited Warranty document for details.
