• 800 lumens ANSI
• 10,000:1 dynamic contrast (under LED control) - No mechanical iris required
• 95% brightness and colour uniformity after electronic adjustment

• Revolutionary solid state projector using a single TI Darkchip 3^™ DMD with a solid state illumination engine (no colour wheel) and sealed optics
• Native 2560 x 1600 WQXGA
• True 120Hz 3D (60Hz per eye content) or 120Hz via frame doubled content (30Hz per eye)

• Signals: Up to 2560 x 1600 WQXGA¹
• 2560 x 1600 @ 60Hz x 2 frame-locked with Dual input 3D for true 120Hz (60Hz per eye 3D), or
• 2560 x 1600 @ 60Hz x 1 for frame doubled output to 120Hz²

• External PC is required for projector operations via Ethernet
• Additional Ethernet connections for Christie ArrayLOC^™ network
• 2 x xRS-232 ports
• 1 x RS-422 port
• 2 x Dual-link DVI-D

Lens mount

• Mechanical, horizontal and vertical lens shift
• No shutter required
• No iris required – user programmable illumination parameters (eliminates the need for a mechanical shutter)

Illumination

• Solid state illumination
• Illumination lifetime greater than 50,000 hours (to 50% output)

Christie ArrayLOC^™

• Manages the brightness and colour levels of all projectors within an array to a common level, in real-time with no additional latency

Fixed

• 0.68:1 WQXGA lens
• 0.80:1 WQXGA lens

Zoom

• 1.28-1.71:1 WQXGA lens

Offsets

• 0.68:1 lens features ±5% (horizontal) and ±15% (vertical) offset when mounted in landscape orientation³
• 0.80:1 lens features +100%/-60% (horizontal) and +150%/-100% (vertical) offset when mounted in landscape orientation³
• 1.28-1.71:1 lens features +100%/-60% (horizontal) and +150%/-100% (vertical) offset when mounted in landscape orientation³

• Line cord
• Christie Twist^™4 optional
• User kit (icludes manual, IR remote)
• Christie AutoCAL^™4
• Chrstie Twist Pro^™4
• Rugged motion platform kit⁵ to withstand 5g shock load (purpose-built)
• Ruggedised transit case
• Remote IR sensor
• Christie MotoBlend^™ optical blending⁶

• Minimum Processing Latency (MPL^™)
• Auto power up
• Menus in 5 languages
• Christie ArrayLOC^™ – automatic, continuous management of brightness and color space levels of all projectors in an array to a common level, in real-time

• Operating voltage: 100-240 VAC 50/60Hz
• Operating current: 10A max 100-120VAC, 5A 200-240VAC (lower in normal operational modes)
• Dissipation: 2316 BTU/hr max. (lower in normal operational modes)

• Size: 15.8" x 15.8" x 16.0" (400 x 400 x 406 mm) without lens
• Weight: 88.2lbs (40kg) without lens
• Shipping weight: 176.4lbs (80kg) without lens

• Temperature: 40-95°F (5-40°C)
• Humidity: 20-80% non-condensing
• Portrait and landscape orientation

• Directives (EC) 2011/65/EU (RoHS)
• 2011/19/EU (WEEE)
• Regulation (EC) No. 1907/2006 (REACH)
• CAN/CSA C22.2 No. 60950-1
• UL 60950-1
• IEC 60950-1
• FCC, Part 15, Subpart B, Class A
• EN55022 / CISPR22 Class A
• EN55024 / CISPR24
• ICEES003 / NMB003 (A)
• Certifications marks and product approvals (check with Christie for latest update): cULus (Canada & US), CE (EU), CCC (China), GoST-R (Russia), KC (Korea), PSE (Japan), C-Tick (Australia & New Zealand); South Africa; Mexico
