Specs
ANALOGUE AUDIO INPUT PORTS
Number of input ports
4 channels:
4 MIC ports
6 ST LINE ports
Connection type
LINE: RCA
1 COMBO MIC (Front panel)
Input sensitivity
LINE, LINE A, LINE B: 0dBV
MICRO (BAL): -35dBV
AUX INPUT IN1: -10dBV
BT INPUT: -10dBVFS
Input impedance
LINE, LINE A, LINE B: 50kΩ
MICRO (BAL): <1kΩ
AUX INPUT IN1: 316Ω
THD + Noise
LINE: <0,03%
MICRO: <0,06%
AUX: <0,03%
BT INPUT: <0,05%
CMRR
BAL INPUTS >75dB @ 1kHz
Phantom power
+48VDC, externally selectable
ANALOGUE AUDIO OUTPUT PORTS
Number of output ports
3: MAIN OUT, SUB OUT, ALT OUT
Connection type
Main: XLR
Sub: XLR
Alt: RCA
Max output level
TBC
Output impedance
TBC
ANALOGUE MONITOR PORTS
Headphones
ST, mini-jack (200mW)
Channels
TBC
DEVICE CONTROL
Tone Control
3-way tone control
Tone Frequency Cut
BASS 100Hz, ± 15dB
MID 2kHz, ± 15dB
TREBLE 10kHz, ± 15dB
Talkover
Yes
Control Buttons
Input selection, ALT OUT send, PAIR, HPF switches, talkover, main out ST/MONO, POWER ON switch, LPF switch, PHANTOM
Status Indicators
SP, CLIP, main OUT - ALT OUT vumeter, POWER LED, PHANTOM LED, talkover
ELECTRICAL
Power supply
External power supply
AC mains requirement
100-240 VAC + External PSU 17.5VDC
AC mains connector
DC power supply connector
Power consumption
15 W
PHYSICAL
Operating temperature
Min: -10°C ; 14°F
Max: 40°C ; 104°F
Operating humidity
<85% HR
Storage temperature
Min: -10°C ; 14°F
Max: 40°C ; 104°F
Storage humidity
<90% HR
Installation options
Desktop, 19" rack format (3RU)
Optional accessories
Rack-mount accessory (3URMKIT)
Dimensions
440 x 132 x 125 mm / 17.32 x 5.2 x 4.92 in. (WxHxD)
Weight
3.0 kg / 6.61 lb
