Ecler HSA 2-400ES wzmacniacz
Możliwość negocjacji ceny.
HSA2-400ES to wzmacniacz stereofoniczny z wyjściami zasilanymi o niskiej i wysokiej impedancji. Bardzo wysoka wydajność i funkcja automatycznego czuwania zapewniają temu wzmacniaczowi prawdziwie ekologiczny profil (certyfikat Energy Star©).
Cechy
- 2 zbalansowane wejścia mono (zaciski XLR i Euroblock)
- Moc wyjściowa 2 x 400 W RMS (4 Ω i poziom liniowy 70/100 V)
- Złącza wyjściowe typu Euroblock
- 2 porty głośności REMOTE (0-10VDC), kompatybilne z panelami ściennymi serii WPa
- Certyfikat Energy Star©
- Wysoka wydajność, funkcja automatycznego czuwania i chłodzenie konwekcyjne (bez wentylatora, 100% ciche)
CHANNELS
Number of output channels
2
Output connection type
Euroblock
Output configuration
2 x 400 W RMS output (4Ω and 70/ 100V line level)
Number of input channels
2
Input connection type
XLR, Euroblock
Input configuration
Balanced inputs
OUTPUT POWER
Max output power @ 4Ω
350W
Max output power @ 8Ω bridge mode
700W
Max output power @ 100V
400W @ 25Ω
SIGNAL
Input sensitivity
0dB
Input impedance
>20kΩ (10kΩ unbalanced)
Frequency response
20Hz – 40kHz (-1dB, -3dB)
THD + Noise
<0.05% @ 1 kHz Full Power
SNR
>85dB @ 1W/4Ω, 20Hz – 20kHz
Crosstalk
>55dB @ 1 kHz
CMRR
>55dB
Damping factor
>360 1kHz @ 8Ω
ELECTRICAL
AC mains requirement
115V/230V @ 47-63Hz. Voltage changed internally (NOT BY SWITCH)
AC mains connector
AC socket connector (IEC)
POWER CONSUMPTION
Power Consumption (1/3 POWER, @ 4Ω)
pink noise, 334W
Power Consumption (1/8 POWER, @ 4Ω)
pink noise, 143 W / 204 VA
Power Consumption (IDLE)
25 W
Power Consumption (STBY)
0.5 W
TECHNOLOGIES
Energy save
Auto standby function
Efficiency
85% @ max power
Cooling
Convection (fanless)
PROTECTIONS
AC protection
No
DC protection
No
VHF protection
No
Shrot-circuit protection
Yes
Clip limiter
Yes
Long term limiter
No
Thermal protection
Yes
REMOTE CONTROL CONNECTIONS
GPIs
x2 GPIs (0-10VDC) for volume control
SETTINGS
Attenuators
Front panel knobs per channel
Filters
50Hz 3rd order Butterworth High-Pass filter
Output settings
Lo-Z/Hi-Z outputs
Auto stand-by function
Rear panel switch
Auto stand-by time
≤120s
Power ON/OFF
Front panel switch & indicator
MONITORING
Signal Present
SP LED (Green) per channel
Cliping
CLIP LED (Red) per channel
Thermal
TH LED (Red)
Standby
STBY LED (Orange) per channel
PHYSICAL
Operating temperature
Min: -10°C ; 14°F
Max: 40°C ; 104°F
Operating humidity
<85% HR
Storage temperature
Min: -10°C ; 14°F
Max: 40°C ; 104°F
Storage humidity
<90% HR
Installation options
19" rack format (2RU)
Optional accessories
WPm series wall panels
Dimensions
482.6 x 88 x 373 mm / 19 x 3.46 x 14.68 in. (WxHxD)
Weight
16.4 kg / 36.15 lb
Shipping dimensions
510 x 200 x 570 mm / 20.1 x 7.88 x 22.45 in. (WxHxD)
Shipping weight
19.3 kg / 42.55 lb
