Specs
INPUTS
Number of inputs
4 analogue input channels.
4 DANTE™/AES67 Network Rx channels.
1 embedded player, 1 embedded signal generator
Analogue input connection type
IN1-4: 3-pin Euroblock, balanced, pitch 3,5 mm
Digital input connection type
Ethernet, managed via Dante™/AES67 Controller
Input configuration
Digital matrix 4 in x 6 out
AMPLIFIED OUTPUTS
Number of amplified outputs
4
Amplified output connection type
2-pin Euroblock. Pitch: 7,62 mm
Ref: DEGSON 5EDGRC-7.62
Output configuration
Lo-Z/Hi-Z, 70V/100V, 4Ω/8Ω/2Ω.
Output mode selection per channel.
VERSAPOWER SYMMETRICAL
Max output power @ 8Ω
400W
Max output power @ 4Ω
400W
Max output power @ 2Ω
400W
Max output power @ 100V
400W
Max output power @ 70V
400W
VERSAPOWER ASYMMETRICAL
Max output power @ 8Ω
1400W
Max output power @ 4Ω
1600W
Max output power @ 2Ω
1600W
Max output power @ 100V
1600W
Max output power @ 70V
1600W
AUXILIAR OUTPUTS
Number of auxiliar outputs
2
Auxiliar output connection type
AUX1-2: 3-pin Euroblock, balanced
DIGITAL OUTPUTS
Number of digital outputs
4
Digital output connection type
Ethernet, managed via Dante™/AES67 Controller
SIGNAL
Voltage gain
28 to 40 dBV
30,2 to 42,2 dBu
Input sensitivity
-6 to +6 dBV
-3,78 to 8,2 dBu
0,5 to 2 Vrms
Input impedance
>24kΩ
Max input level
+18 dBV
+20,2 dBu
Frequency response
15Hz-25kHz
THD + Noise
< 0,1%
0,015 Typ
SNR
95 dBA
Crosstalk
>80 dB
CMRR
>65 Typ
Damping factor
>500
ELECTRICAL
Power supply
Universal, regulated SMPS with PFC
AC mains requirement
100-240 V @ 50-60Hz (±10%)
Power factor correction
> 0,96
AC mains connector
IEC C14 inlet
POWER & HEAT @230VAC - 1/4 POWER, @ 4Ω
Power
607 W
640 VA
Current Draw
2,8 Arms
Thermal Loss
178,0kcal/h
706,5BTU/h
POWER & HEAT @230VAC - 1/8 POWER, @ 4Ω
Power
362 W
414 VA
Current Draw
1,8 Arms
Thermal Loss
139,3kcal/h
552,9BTU/h
POWER & HEAT @230VAC - IDLE
Power
72 W
122 VA
Current Draw
0,52 Arms
Thermal Loss
61,9 kcal/h
245,7 BTU/h
POWER & HEAT @230VAC - SLEEP MODE
Power
4,1 W
23,8 VA
Current Draw
0,1 Arms
Thermal Loss
3,5 kcal/h
14 BTU/h
POWER & HEAT @120VAC - 1/4 POWER, @ 4Ω
Power
604 W
611 VA
Current Draw
5,17 Arms
Thermal Loss
175,4kcal/h
696,3BTU/h
POWER & HEAT @120VAC - 1/8 POWER, @ 4Ω
Power
354 W
362 VA
Current Draw
3,04 Arms
Thermal Loss
132,4kcal/h
525,6BTU/h
POWER & HEAT @120VAC - IDLE
Power
68 W
89 VA
Current Draw
0,75 Arms
Thermal Loss
58,5 kcal/h
232,1 BTU/h
POWER & HEAT @120VAC - SLEEP MODE
Power
3,6 W
10,2 VA
Current Draw
0,09 Arms
Thermal Loss
3,1 kcal/h
12,3 BTU/h
TECHNOLOGIES
Amplification technology
Class D
Energy saving
Auto standby function programmable per channel
Sleep Mode funtion selectable
Efficiency
68%
Cooling
Fan
Maximum fan noise
45 dB
PROTECTIONS
DC protection
Yes
HF protection
Yes
Short-circuit protection
Yes
Clip limiter
Yes
Long term limiter
Yes
Thermal protection
Yes
REMOTE CONTROL CONNECTIONS
ON / OFF
No
GPIs
x4 GPIs (0-10V)
GPOs
x4 NC / NO contacts
External MUTE
Yes, contact
LOCAL CONTROL
Attenuators
Programmable Front panel knobs
Output mode settings
Lo-Z/Hi-Z, 70V/100V, 4Ω/8Ω/2Ω
Output mode selection per channel
RUN/SLEEP mode
Yes, front panel push-button
Power ON/OFF
Yes, back panel switch
CONNECTIVITY
Ethernet
Ethernet Base-Tx 10/100/1000Mb Auto X-Over
DANTE Protocol
Dante™/AES67 4x Tx / 4x Rx channels
Primary and secondary capability. RJ-45 ports
Programing and control
Embedded web application
MONITORING
Signal Present
SP LED (White) per channel
Cliping
CLIP LED (Red) per channel
Protect
PROT LED (Red) per channel
Standby / Mute
STBY/MUTE LED (White) per channel
Limit
LIMIT LED (Red) per unit
Thermal
THERMAL LED (Red) per unit
Dante
DANTE™/AES67 LED (White) per unit
Data
DATA LED (White) per unit
On
ON LED (White) per unit
DIGITAL ENGINE
Processor
Quad core 64bits 1,5GHz
AUDIO CONVERTERS
Sampling rate
48 kHz
Resolution
24 bit
Dynamic range
114 dB
PROCESSING
Digital processing
32/64 bit
Latency
2,8 ms
Inputs processing
Noise gate, HPF, Freq. Shifter, compressor/limiter
Outputs processing
Delay, Parametric EQ, Graphic EQ independent for every amp out and aux out
Limiters independent for every amp out
Smart VersaPower management
Others
Preset management, Internal matrix, priority & backup signals managemnet, local & network groups, events management incl. calendar
REAL-TIME CLOCK
Retention time
> 5 years
Accuracy
±1 minute / month
Battery
VARTA CR2032 3V, 230mAh
LOCAL STORAGE
Micro SD
SDXC
Capacity
Up to 2TB
File system
FAT16, FAT 32, VFAT (read/wirte)
NTFS (read)
Multi-partition up to 1
Playable audio files
mp3, ogg, WAV, FLAC, AIFF
Files analysis
65354 playable folders
65354 playable folders within each folder
65354 playable files within each folder
Folder hierarchy
Up to 8 containing the root directory
Sorting
UNICODE, in alphabetical order
Up to 100 folders / files by folder
Folders/files over 100 sorted in the FAT order
PHYSICAL
Operating temperature
Min: -10⁰C ; 14⁰F
Max: 50⁰C ; 122⁰F
Operating humidity
5 - 85% RH, non-condensing
Storage temperature
Min: -10⁰C ; 14⁰F
Max: 50⁰C ; 122⁰F
Storage humidity
5 - 85% RH, non-condensing
Installation options
Rack 19" installation & desktop
Included accessories
Mains cords, Euroblock Connectors (inputs /outputs), Desktop feet, rack 19" installation hardware
Dimensions
482.6 x 88 x 410 mm / 19 x 3.46 x 16.14 in. (WxHxD)
Weight
9.3 kg / 20.5 lb
Shipping dimensions
650 x 125 x 600 mm / 25.59 x 4.92 x 23.62 in.
Shipping weight
12.3 kg / 27.1 lb
