Panel

Screen Size (diagonal) 70“

Active Display Area (in/mm) 61 x 34.31 / 1549.45 x 871.55

Resolution 1920 x 1080

Aspect Ratio 16:9

Display Colors 16.7M

Brightness (cd/m²; typ.) 400

Contrast Ratio 4000:1

Response Time (ms; GTG) 8

Viewing Angle 178°/178°

Lifetime (hours) 50,000

Backlight type LED

Touch Screen

Touch Size (W x H x D) mm 1616 x 937 x 12.5

Available Touch Point 1~6 Point

Response Time (ms) 1P Touch : 9 / 6P Touch : 24

Glass Transmission: 93%, Thickness: 5 mm

Available object size

for Touch (mm)

Touch : Ø 10

Drawing : Ø 12

Others USB 1/2.0 Full Speed | Detection Method : Infrared Rays | HID compatible : Windows

Input VGA(D-Sub) | HDMI | DVI | IR | PC Audio | RS232C

Output DVI | IR | RS232C | Audio Line Out | Speaker (Ready)

Power

Input Voltage 100 – 240V AC

Power consumption 300W

Features

Fanless yes

Auto Power Control yes

Auto Brightness Sensor yes

Operation Temperature (ºC) 0 - 40

Humidity (%) 20 - 80

OSD Language 10 Lang

Dimension Set (W x H x D), in/mm 63.83 x 37.09 x 3.26 / 1621.5 x 942.15 x 82.7

Bezel Size (U/D/L/R), in | mm 1.31/1.31/1.23/1.23 | 33.2/33.2/31.3/31.3

Wall Mounting (WxH) mm 800 x 600 / 400

Weight Set (lb/kg) 154 / 70
