Panel

Screen Size (diagonal) 55“ 70“ 84“

Active Display Area (mm) 1209.6(H) x 680.4(V) 1549.44(H) x 871.56(V) 1860.48(H) x 1046.52(V)

Resolution 1920 x 1080 (WUXGA) 1920 x 1080 (WUXGA) 3840 x 2160 (QWUXGA)

Aspect Ratio 16:9

Display Colors 16.7 M 16.7 M 1.06B

Brightness (cd/m˛; typ.) 350 400 350

Contrast Ratio 1400:1 4000:1 1600:1

Response Time (ms; GTG) 6 8 5

Viewing Angle 178°/178°

Lifetime (hours) 50,000

Backlight type LED

Touch Screen

Touch Accuracy (typ.) ±2mm

Resolution 32767 x 32767

Response Time (ms, typ.)/Rate 9 / 125 rps

Touch Method Pointer including fingers

Multi-Touch 4 point

Interface USB 2.0 compatible(full speed), HID compatible, Plug & Play compatible

Touch Intensity over 60,000,000

Detection Method Infrared CMOS camera sensors

Operating Systems Windows XP / Vista/7/8, Linux, Mac OSX Windows

Resolution

Monitor 1920 x 1080

DTV 1080p

Input

Video VGA (D-Sub) | HDMI | DVI | Component (BNC);E70AL/E84AL

Audio PC Audio | Component Audio;E70AL/E84AL | Composite Audio;E70AL/E84AL | RS232C

Output

Video VGA (D-Sub) | HDMI | RS232C

Speaker 10 W x 2 CH

Power

Input Voltage 100 – 240V AC

Power consumption 150 W 300 W 450 W

Features

Anti Glare yes

Auto Power Control yes

Auto Brightness Sensor yes

Tempered Glass yes

Option PIR Sensor (Motion detection)

Operation Temperature (şC) 0 - 40

Humidity (%) 20 - 80

Wall Mounting (WxH), mm 300 x 300 / 400 x 400 / 600 x 400 800 x 400, 800 x 600 800 x 400, 800 x 600

Dimension Set (W x H x D) mm 1387.6 x 836.4 x 64 1728.7 x 1028.8 x 80 2039.75 x 1203.75 x 85

Weight Set (lb/kg) 45 74 98.5
