Panel
Diagonal Size
55"

Type
120Hz E-LED BLU
Resolution
1920*1080 (Full HD)

Pixel Pitch(mm)
0.630 x 0.630
Active Display Area(mm)
1209.6(H) x 680.4(V)
Brightness(Typ.)
4000 nit

Contrast Ratio
6000:1
Viewing Angle(H/V)
178/178

Response Time(G-to-G)
6ms
Display Colors
8 bit - 16.7M
Color Gamut
72%
Operation Hour
24/7

Haze
0%
Display
H-Scanning Frequency
30 ~ 135kHz (DP), 15 ~ 135kHz (HDMI)
V-Scanning Frequency
30 ~ 75Hz (DP), 24 ~ 75Hz (HDMI)
Maximum Pixel Frequency
533.25MHz (DP), 594MHz (HDMI)
Connectivity
Input
RGB
Display Port 1.2 (1)
Video
HDMI2.0 (2)

HDCP
HDCP 2.2
USB
USB 2.0 (1)
Output
RGB
HDMI 2.0
Video
Yes
Audio
Stereo Mini Jack
External Control
RS232C (In/Out), RJ45 (In/Out)

External Sensor
Detachable Type (IR, Ambient)
Power
Type
Internal
Power Supply
AC 100 - 240 V, 50/60 Hz
Power Consumption
Max[W/h]
450W

Typical[W/h]
276W ※ IEC 62087 measurement standard

BTU(Max)
1536W
Sleep mode
less than 0.5W
Mechanical Specification
Dimension (mm)
Set
1253.4 x 724.2 x 54.5 mm
Package
1420 x 879 x 178 mm
Weight (kg)
Set
23.1kg
Package
29.1kg
VESA Mount (mm)
400 x 400 mm
Bezel Width (mm)
19.9 (even)
Operation
Operating Temperature
0℃~ 30℃ (Direct Sunlight) 0℃~ 40℃ (w/o Direct Sunlight)

Humidity
10 % ~ 80 %
Feature
Key Features
High brightness Semi-Outdoor / Slim & Clean back design / Built-in MagicInfo Player S7, SSSP 7.0

Orientation
Landscape / Portrait

Remote Control
N/A
Special Features
IP 5X rated, Polarized Sun Glasses Viewable in any direction, Portrait /Landscape Installation Support, Auto Brightness Control with Ambient Brightness Sensor, Temperature Sensor, RJ45 MDC, Auto Source Switching & Recovery, Clock Battery(80hrs Clock Keeping), Kensington Lock, WiFi Module Embedded
Internal Player
Processor
Cortex A72 1.7GHz Quad-Core CPU

On-Chip Cache Memory
L1 Instruction Cache : 48KB / L1 Data Cache : 32KB / L2 Cache : 2MB

Clock Speed
1.7GHz

Main Memory Interface
2.5GB / LPDDR4 1.5GHz 64bit
Graphics
Graphic resolution : 1920x1080 / Output resolution : 1920x1080 - Supports OpenGL ES

Storage (FDM)
8GB (3.88GB Occupied by O/S, 4.12GB Available)

Multimedia
Video Decoder FHD MFD : VP8, H.264, AVS+(60Hz)UHD MFD : HEVC, H.264, VP95K HEVC Decoder, SHVC(ATSC3.0)AVS2.0 HEVC / AVS2.0 1xUHD120p (DP_NR off, FRC bypass) Audio Decoder - AC3 (DD), MPEG

IO Ports
USB 2.0
Operating System
Tizen 5.0 (VDLinux)
Certification
Safety
60950-1

EMC
Class A
Accessory
Included
Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote Controller, Batteries, IR, Ambient sensor
Optional
Stand
N/A

Mount
N/A

Specialty
N/A
Media Player
Media Player
Media Player
N/A
