Dane techniczne
Common Item
Model Year2023
TV System
TV System (Analog)B/G,D/K
Tuner Channel Coverage (Analog)45.25MHz-863.25MHz(Depend on country selection)
TV System (Digital Terrestrial)DVB-T/T2
Tuner Channel Coverage (Digital Terrestrial)VHF/UHF(Depend on country selection)
TV System (Digital Cable)DVB-C
Tuner Channel Coverage (Digital Cable)VHF/UHF/cable(Depend on country selection)
TV System (Digital Sat)DVB-S/S2
Tuner Channel Coverage (Digital Sat)Intermediate Frequency 950-2150MHz
Number of Tuners (Terrestrial/Cable)1(Digital/Analog)
Number of Tuners (Sat)1
Color SystemPAL/SECAM/NTSC3.58(Video only)/NTSC4.43(Video only)
CI+Yes
Color SpacesRGB/BT709,BT2020,AdobeRGB,DCI
Operating SystemAndroid 10
On-board Storage (GB)32GB
Display Features
X-Anti Reflection-
Display typeLCD
X-Wide Angle-
Pixel Contrast Booster-
Rich Color Enhancer-
Backlight dimming typeFrame Dimming
Display Specs
Screen Size (inch, measured diagonally)55"(54.6")
Screen Size for WEB(diagonal, cm, integer or 1st decimal)139 cm
Backlight typeDirect LED
Display resolution (H x V, pixels)3840 x 2160
Viewing Angle (Right/Left)178(89/89) degree
Viewing Angle (Up/Down)178(89/89) degree
Display ResolutionQFHD
Aspect Ratio16:9
Video Features
XR Backlight Master Drive-
Object-based Super Resolution-
Peak Luminance-
TRILUMINOSTRILUMINOS PRO
HDR RemasterObject-based HDR remaster
Smoothing-
Features for PlayStation®5 Auto HDR Tone MappingYes
Features for PlayStation®5 Auto Genre Picture ModeYes
XR Clear Image-
Precision Color Mapping- (Integrated into TRILUMINOS PRO)
LED Motion Mode-
Face Area Detection-
Mastered in 4K-
Picture modesVivid,Standard,Cinema,Game,Graphics,Photo,Custom,Dolby Vision (Vivid/Bright/Dark)
Auto WideYes
Wide ModeWide zoom/Normal/Full/Zoom/14:9,Normal/Full1/Full2 for PC
4:3 DefaultYes
Video Processing4K X-Reality PRO
Motion enhancerMotionflow XR 200/240Hz (Native 50/60Hz), Auto mode
Blinking TypeFrame Blinking
24p True CinemaYes
Live Colour™ TechnologyYes
PhotoTV HD / BRAVIA 照片秀 for ChinaYes
CineMotion/Film Mode/Cinema DriveYes
4K Processor4K HDR Processor X1
HDR (High Dynamic Range) compatiblityYes(HDR10,HLG,Dolby Vision)
Panel Refresh Rate (Native Hertz)50/60Hz
Dual database processing-
Dynamic Contrast EnhancerYes
Audio Specs
Channel2ch
Audio Power Output10W + 10W
Speaker PositionDown Firing
Bass/Treble/BalanceBalance
Speaker TypeBass Reflex Speaker
Speaker ConfigurationFull Range (Bass Reflex) x 2
DSEE/DSEE-HX-
Digital audio out (Optical) formatTwo channel linear PCM: 48kHz 16bits, Dolby Audio, DTS(Pass through mode only)
Audio Features
Acoustic Center Sync-
Ready for 360 Spatial Sound Personalizer-
Simultaneous Sound Output with TV Speaker-
Vertical Surround Engine-
Acoustic Auto CalibrationRoom Compensation
Speaker Type-2X-Balanced Speaker
Clear PhaseYes
Clear Audio+-
S-MasterS-Master Digital Amplifier
Auto SurroundYes
DTS audio format supportDTS Digital Surround
Sound modes-
Simulated surround sound-
Dolby audio format supportDolby Audio, Dolby Atmos
Voice Zoom-
HDMI Audio Return Channel(ARC)Yes (eARC/ARC)
Advanced Auto VolumeYes
Auto Mute (on no signal)Yes
FM Radio-
Audio Out-
Headphone/Speaker Link-
HDMI input Audio format5.1 channel linear PCM: 32/44.1/48/88.2/96/176.4/192kHz 16/20/24bits, Dolby Audio, Dolby Atmos, DTS
ARC output formatTwo channel linear PCM: 48kHz 16bits, Dolby Audio, Dolby Atmos, DTS(Pass through mode only)
Network Features
Control MenuYes
ECO DashboardYes
USB Tethering-
Apple AirPlayYes
Apple HomeKitYes
Home Network FeatureHome Network Client, Home Network Renderer
Wi-Fi DirectYes
Wi-Fi CertifiedYes
Screen mirroring(Miracast™)Yes (only for B2B purpose)
Video & TV SideView (iOS/Android)Yes
Related InfoYes (UK, Ireland, Netherlands, Belgium, Luxembourg, France, Italy, Germany, Austria, Switzerland, Spain, Poland, Czech, Russia, Finland, Denmark, Sweden, Norway, Slovakia)
Wi-Fi Standarda/b/g/n/ac
Wi-Fi Frequency2.4GHz/5GHz(for Wi-Fi Direct: 2.4GHz Only)
Photo Sharing Plus / Photo Share-
Internet BrowserYes
Codec for Home NetworkMPEG1:MPEG1/MPEG2PS:MPEG2/MPEG2TS(HDV,AVCHD):MPEG2,AVC/MP4(XAVC S):AVC,MPEG4,HEVC/AVI:Xvid,MotionJpeg/ASF(WMV):VC1/MOV:AVC,MPEG4,MotionJpeg/MKV:Xvid,AVC,MPEG4,VP8.HEVC/WEBM:VP8/3GPP:MPEG4,AVC/MP3/ASF(WMA)/LPCM/WAV/MP4AAC/FLAC/JPEG,WEBM:VP9/AC4/ogg/AAC/ARW(Screen nail only)
Wireless LANIntegrated
Convenience Features
Function by Camera-
UVC/UAC supportYes
Multi-View-
Color Inversion-
TalkBackYes
Variable Refresh Rate (VRR)-
Auto Low Latency Mode (ALLM)Yes (for HDMI3/4)
Features specified in HDMI2.1eARC/ALLM
Built-in Mic switchYes(Center)
X-Protection PROY (with Lightning, Surge, Humidity Protection)
Electronic Program Guide (EPG)Yes
USB HDD RecordingYes(1Rec)(Except Italy)
Twin Picture-
Photo Frame Mode-
USB playback codecsMPEG1:MPEG1/MPEG2PS:MPEG2/MPEG2TS(HDV,AVCHD):MPEG2,AVC/MP4(XAVC S):AVC,MPEG4,HEVC/AVI:Xvid,MotionJpeg/ASF(WMV):VC1/MOV:AVC,MPEG4,MotionJpeg/MKV:Xvid,AVC,MPEG4,VP8.HEVC/WEBM:VP8/3GPP:MPEG4,AVC/MP3/ASF(WMA)/LPCM/WAV/MP4AAC/FLAC/JPEG,WEBM:VP9/AC4/ogg/AAC/ARW(Screen nail only)
Built-in MicYes
Screen ReaderYes
Audio DescriptionYes
Text MagnificationYes
Accessibility ShortcutYes
Switch AccessYes
Auto Picture ModeYes
Text Input LanguageARA / BUL / CAT / HRV / CES / DAN / DUT / ENG / EST / FIN / FRA / GER / GRK / HEB / IND / ITA / JPN / NOR / FAS / POL / POR / RON / RUS / SLK / SLV / SPA
Chromecast built-inYes
Voice SearchYes*1

*1 Hands Free feature(Built-in Mic) availability depends on language and may need software update. Please check Sony support page for further information; https://www.sony.net/tv-hf-ww/
Application StoreYes (Google Play Store)
BRAVIA Sync (including HDMI-CEC)Yes
Control for HDMI (HDMI CEC)-
Scene Select-
i-ManualYes
Parental ControlYes
Channel Block (with password)Digital
Show/Hide Channels-
On Screen ClockYes
Sleep TimerYes
On/Off TimerYes
USB drive format supportYes (Supported File System: FAT16/FAT32/exFAT/NTFS)
Display LanguageAFR,AMH,ARA,ASM,AZE,BEL,BUL,BEN,BOS,CAT,CZE,DAN,DEU,GRE,ENG,SPA,EST,BAQ,PER,FIN,FRA,GLG,GUJ,HIN,HRV,HUN,IND,ISL,ITA,HEB,JPN,KAZ,KAN,KOR,KIR,LAO,LIT,LAV,MAC,MAL,MON,MAR,MAY,BUR,NOB,NEP,NLD,ORI,PAN,POL,POR,RUM,RUS,SOL,SLV,ALB,SRP,SWE,SWA,TAM,TEL,THA,TGL,TUR,UKR,URD,UZB,VIE,zh_CN,zh_HK,zh_TW,ZUL
Auto Shut-off-
Sensing Features
SensorLight
General Features
Smart TVGoogle TV
BRAVIA CORE Calibrated mode-
Auto Calibration with CalMANYes
Netflix Calibrated mode-
Tencent Calibrated mode-
IMAX Certified Model-
Closed Captions (Analog)-
Closed Captions (Digital)Subtitle
Demo ModeYes(e-POP only)
Emergency Warning System-
Hotel Mode Menu-
Broadcast Features
TeletextYes
Teletext number of pages1000 pages
Customizing Capability
RS-232C Control-
Design Features
Style-
Stand Position#2way position (Standard position/Narrow position)
Stand ColorBlack
Bezel DesignFlush Surface
Cable ManagementYes
Frame colorBlack
Stand DesignSlim T shape Wedged Stand
Illumination LED-
Stand Swivel-
Stand Tilt-
Inputs and Outputs
Media Connect-
HDMI Signal4096x2160p(24,50,60Hz), 3840x2160p(24,25,30,50,60Hz), 1080p(24,30,50,60Hz), 1080i(50,60Hz), 720p(24,30,50,60Hz), 576p, 480p
HDCPHDCP2.3(for HDMI1/2/3/4)
Bluetooth profile supportVersion 4.2,HID/HOGP/SPP/A2DP/AVRCP
4K 60P High-Quality formatsHDMI IN1, IN2, IN3, IN4 ports for 4K(up to 18Gbps) signal
AC Power InputC8 INLET(REAR)
RF (Terrestrial/Cable) Connection Input(s)1(Side)
IF (Satellite) Input(s)1(Side)
Composite Video Input(s)1(Side, Mini jack)
Component Video (Y/Pb/Pr) Input(s)-
HDMI inputs total4(4Side)
PC In (D-Sub) + Audio In (Stereo Mini)-
Analog Audio Input(s) (Total)1(Side Analog Conversion)
Digital Audio Output(s)1(Side)
Audio Output(s)-
Headphone Output(s)-
Subwoofer Output(s)-
USB ports2 (Side)
Ethernet inputs1(Side)
RS-232C Input(s)-
PCMCIA Slot(s)1(Top)
HDMI PC Input Format640x480(31.5kHz,60Hz), 800x600(37.9kHz,60Hz), 1024x768(48.4kHz,60Hz), 1280x1024(64.0kHz,60Hz), 1152x864(67.5kHz,75Hz), 1600x900(55.9kHz,60Hz), 1680x1050(65.3kHz,60Hz), 1920x1080(67.5kHz,60Hz), 3840x2160p(30Hz), 3840x2160p(60Hz, 8bits)
Eco and Energy saving
Power Requirements (voltage)220 V - 240 V AC
Power Requirements (frequency)50 Hz
Power Consumption (Home Mode) for WEB-
Power Consumption (in Standby)0.50 W
Power consumption(Networked Standby)2.00W(Wi-Fi) / 2.00W(LAN) / 0.50W(CEC)
SORPLAS-
EEA SDR RANKG
ECO FriendlyYes
On Mode Power Consumption (Lot 5)91 kWh/1000h
ErP Rank For EU-
Peak luminance ratio for EU-
Mercury content(mg)0.0
Lead ContentYes
Dynamic Backlight ControlYes
Power Saving Mode / Back Light Off ModeYes
Regulation and Standard Compliance
VESA® Hole Spacing CompatibleYes
VESA® Hole Pitch(W x H)30.0 x 30.0 cm
Measurements (Approx.)
Dimension of TV without Stand with Camera (W x H x D)-
TV with Stand (Front position) (W x H x D) *Measured incl. camera if bundled-
TV with Stand (Back position) (W x H x D) *Measured incl. camera if bundled-
Stand Width (Front position style)-
Stand Width (Back position style)-
Dimension of TV without Stand (W x H x D)Approx. 123.3 x 71.3 x 7.2 cm
TV with Stand (Standard position) (W x H x D)Approx. 123.3 x 78.5 x 33.6 cm
TV with Stand (Narrow position) (W x H x D)Approx. 123.3 x 78.5 x 33.6 cm
TV with Stand (Soundbar position) (W x H x D)-
Dimension of TV with Floor Stand (W x H x D)-
Dimension of Package Carton (W x H x D)Approx. 134.8 x 84.2 x 16.0 cm
Stand width (Standard position)Approx. 107.2 cm
Stand width (Narrow position)Approx. 46.9 cm
Stand width (Soundbar position)-
Floor Stand Width-
AC Power Adapter size(W x H x D)-
DC Cable length of AC adaptor(mm)-
AC Cable Length1500mm
Weights (Approx.)
TV with Stand (Front position style/Back position style)-
Weight of TV without StandApprox. 15.9 kg
TV with Stand (Standard position)Approx. 17 kg
TV with Stand (Narrow position)Approx. 17 kg
TV with Stand (Soundbar position)-
Weight of TV with Floor Stand-
Weight of Package Carton(Gross)Approx. 23 kg
Carton Spec
Max Qty of carton stacking (vertical)6
Max Qty of carton stacking (horizontal) *only for Shop FrontN/A
Supplied Accessories
Camera Unit (Bundle)-
Voice Remote Control (Supply)RMF-TX810U
Remote ControlRMT-TX450E
AC Plug Convertor-
Wall-Mount Bracket-
Android TV Setup Guide-
BatteriesLR03+R03
Floor Stand (Supply)-
AC Power Adaptor-
AC Power Cord SpecBundle (C7L) (UK) (3pin) (flat blades)
IR Blaster-
Support Belt-
Operating InstructionsEN,FR,ES,NL,DE,PT,IT,SE,DK,FI,NO,PL,CZ,SK,HU,RO,BG,GR,TR
Quick Setup Guide / Supplement CUE (GA)EN,FR,ES,NL,DE,PT,IT,DK,NO,SE,FI,PL,CZ,SK,HU,RO,BG,GR,TR,RU,UA,AR
Table Top StandSeparate (Assembly required)
Optional Accessories
Camera Unit (option)CMU-BC1
Floor Stand (Option)-
Wallmount BracketSU-WL450(Terminal access limitation, refer to SU-WL450 product page), SU-WL850(Depends on usage of terminal)
PrimeSupport
Included PrimeSupport3 Years with advanced exchange handled by local partner, on premise where possible.
Optional +2 years extension.
