Podstawowe cechy:

• Rozmiar24
• Przekątna (cm)60.96
• Rodzaj podświetlaniaLED
• Rozdzielczość natywna1920 x 1080 FullHD
• Jasność250 cd/m2
• Czas reakcji16 ms
• Kontrast3000:1
• Wbudowany głośnik2 x 2.5W
• Redukcja migotaniatak
• Filtr niebieskiego światłatak
• Standard VESA (mm)100 x 100
• Wymiary (z podstawą)572.9 x 351.8 x 47 mm
• Waga (netto)5.64 kg
• Waga (z opakowaniem)7.56 kg
• Wyposażenie standardoweKabel zasilający
• Skrócona instrukcja obsługi
• PortyHDMI
• USB-B (obsługa funkcji dotykowej)
• Dodatkowe porty komunikacyjneMini USB
• RJ-45
• SD

Specyfikacja techniczna:

• OPERATING SYSTEM

  Platform: Support Android 8.0

  Type: 23.6” TFT liquid crystal display, VA panel

• PANEL

  Type: 23.6” TFT liquid crystal display, VA panel

  Resolution: 1920 x1080

  Color Depth: 8-bit + Hi FRC

  Brightness: 250 cd/m2 (typ.) & 200 cd/m2 ( Min.)

  Contrast: 3000:1 (typ.) / 2000:1 ( Min.)

  Touch Panel: PCT10 points touch supported

  Surface Treatment: Touch CS Soda-Lime glasses (≧7H)

  Viewing Angle: View Angle Free (R/L 178 – Typ.)

  Response Time: 16 ms GTG ( typ.)

• PROCESSOR

  CPU Processor Type: Rockchip® RK3288 Cortex-A17 ( Quad- Core 1.8 GHz)

  Scalar: Realtek RTD2483AD-CG

• MEMORY

  System: 16GB eMMC iNand

  Storage: 2GB DDR3

• AUDIO

  Microphone: Yes

  Speaker: 2.5W *2 stereo

  Headset: 3.5mm audio jack for stereo headset

• SOFTWARE

  Protocols: Support Android 8.0

• CONNECTIVITY

  GPS: N/A

  WiFi: WiFi :802.11 b/g/n

  Bluetooth: BT4.0

  USB: USB2.0 -typeA*4 ; USB type B*1 ; Mini-USB for OTG

  HDMI-IN: Yes

  HDMI-OUT: Yes

  RJ45 LAN: 10M/100M/1000M

  Screen Mirroring: Yes ( depends on receiver compatibility)

• CAMERA

  Primary Camera (Rear): N/A

  Secondary Camera (Front): View Angle Free (R/L 178 – Typ.)

  Response Time: 5.0MP Autofocus

• SENSOR

  Gravity sensor: N/A

  E-compass sensor: N/A

  Abmient light sensor: N/A

  Proximity sensor: N/A

  Gyro-sensor: N/A

• SUPPORTED FILE

  Text: TXTJPEG/BMP/ GIF (non-animated)

  Picture: AVI，RM，RMVB，MOV，FLV，3GP，MP4，MKV

  Video: Multi Format Codec provides encoding and decoding of MPEG-4/H.263/H.264 up to 1080p@30fps and decoding of MPEG-2/VC1 video up to 1080p@30 fps

• POWER

  Voltage: AC Input voltage 100~240VAC, 50/60Hz (universal)

  Consumption: - On mode: 40 W (Max)

  -Standby Mode: < 2 W

  -Off mode : 0.5 W

• INTERFACE

  I/O ports: 3.5mm headset jack

  3.5mm Microphone-IN jack

  DC jack

  SD card slot

  HDMI-IN

  HDMI-OUT

  RJ45 LAN

  MiniUSB*1-OTG

  USB 2.0*4 – type A

  USB 2.0*1 –type B*

  *( Extermal HDMI display mode for USB upstream, and Touch-screen

  control functionality.)

• ERGONOMICS

  Tilt: N/A

• OPERATING CONDITIONS

  Temperature (º F / º C): 0°C to 35°C

  Humidity: 20%~90% non-condensing

• DIMENSIONS (W X H X D) (INCH / MM)

  Physical with stand (inch/mm): 572.9 x 351.8 x 47mm ( 22.6 x 13.9x 1.9 inches)

  Physical without stand (inch/mm): N/A

  Packaging (inch/mm): 643 x 435 x 140 mm

  ( 25.32 x 17.13 x4.93 inches)

• WEIGHT

  Net with stand (lb / kg): 5.64 kg

  (12.43 lb)

  Net without stand (lb / kg): N/A

  Gross (lb / kg): 7.56 Kg

  (16.65 lb)

• WALL MOUNT

  VESA®: 100x100mm

• REGULATIONS

  FCC, cUTVus, FCC-ID, IC-ID, CE, CB, R&TTE, RoHS, ErP, WEEE,

• RECYCLE / DISPOSAL

  Please dispose of in accordance with local, state or federal laws

• WARRANTY

  *Warranty offered may differ from market to market

• WHAT'S IN THE BOX

  1. VSD243

  2. Power adapter with

  3. Power cord (depend on regions.)*

  4. Quick Start Guide

  * Applicable power cord is shipped with the product to the point of

  destination.

  *Actual content may differ from market to market
