| Native Resolution |
1080p (1920 x 1080) |
| Brightness |
4800 ANSI Lumens |
| Contrast Ratio |
15,000:1 |
| Max. Resolution |
WUXGA (1920x1200) @60Hz |
| Native Aspect Ratio |
16:9 |
| Lamp Life and Type |
2,500/ 3,500/ 4,000 Hours (Normal /Eco/Dynamic Eco Mode) 310W/245W |
| Display Type |
Single 0.65" DLP Technology by TI |
| Throw Ratio |
1.39 – 2.09 |
| Image Size (Diagonal) |
25.9" - 324.9" |
| Projection Distance |
1.2m - 10m |
| Projection Lens |
F/#2.42 - 2.97, f=20.9 - 31.05 |
| Zoom Ratio |
1.5x |
| Lens Shift ( Based on Full Image Height) |
Vertical:111.2% - 130.8%, +/- 5% |
| Offset ( Based on Full Image Height) |
115%, +/-10% |
| Keystone Correction |
Vertical +/- 30° |
| Speakers |
3W (Mono) |
| Video Compatibility |
SDTV(480i, 576i), EDTV (480p, 576p), HDTV (720p, 1080i/p), NTSC (M, 3.58/4.43 MHz), PAL (B, D, G, H, I, M, N), SECAM (B, D, G, K, K1, L) |
| I/O Connection Ports |
VGA-In (15pin D-Sub) (x2), VGA adaptor - 24pin Universal input, HDMI (x2), Display Port, S-Video, Composite Video, Audio-In (RCA), Audio-In (Mini-Jack), VGA-Out (15pin D-Sub), Audio-Out (Mini-Jack), RJ45 (1x), 12v Trigger, RS-232, 3D-Sync Out, USB miniB mini USB ( Service) |
| Dimensions (W x D x H) |
332.8 x 255 x 114.6mm |
| Weight |
3.95kg kg |
| Noise Level |
36dB/30dB (Normal/Eco. Mode) |
| Power |
Power Supply: AC 110-240V, 50/60Hz. Power Consumption: 370W (Normal Mode), 300W (Eco. Mode), <0.5W (Standby Mode) , <6W (LAN Standby Mode) |
| Spare Lamp P/N |
5811118436-SVV |
| Remote Control P/N |
5041818400 |
| Standard Accessories |
VGA Cable, User Manual (CD), Lens Cap, Carrying Case, Remote Controller (with battery) |
| Optional Accessories |
Spare Lamp P/N: 5811118436-SVV , Remote Control P/N: 5041818400 |
| Warranty |
Standard Warranty: 3 years projector / 1 year on lamp or 1000 hours whichever comes first |
| UPC Code |
813097 021427 |
