| Native Resolution |
WUXGA (1920 x 1200) |
| Brightness |
6000 ANSI Lumens |
| Contrast Ratio |
20,000:1 |
| Max. Supported Resolution |
WUXGA (1920 x 1200) @60Hz |
| Native Aspect Ratio |
16:10 |
| Lamp Life and Type |
Lamp free design. Laser light source lasts up to 20,000 hours |
| Display Type |
Single chip DLP® Technology by Texas Instruments |
| Chip Size |
0.67” DMD |
| Throw Ratio |
1.15 - 1.90 : 1 |
| Image Size (Diagonal) |
37" - 201" |
| Projection Distance |
1.5 - 5.0 m |
| Projection Lens |
F = 2.45 - 3.13, f = 17.23 - 27.9 mm |
| Zoom Ratio |
1.65x |
| Lens Shift Range |
Vertical: +12%; Horizontal: +/-2.5% |
| Offset |
115% and Manual Lens Shift |
| Keystone Correction |
Vertical: +/-30°; Horizontal: +/-30° |
| Speakers |
5W x 2 |
| Video Compatibility |
SDTV (480i, 576i) / EDTV (480p, 576p) / HDTV (720p, 1080i, 1080p), NTSC (M, 3.58/4.43 MHz), PAL (B,D,G,H,I,M,N) SECAM (B,D,G,K,K1,L) |
| I/O Connection Ports |
VGA-In (15pin D-Sub), HDMI Number of Ports (x3: HDMI/MHLx1, HDMIx2), Composite Video, Audio-In (RCA) , Audio-In (Mini-Jack), VGA-Out (15pin D-Sub), Audio-Out (Mini-Jack), RJ45 (x2: HDBaseTx1, LANx1), RS-232, 3D-Sync (1: Out), USB A (Power Only), USB miniB (Service), Microphone (Mini-Jack) |
| Dimensions (W x D x H) |
360 x 451.5 x 151 mm |
| Weight |
10.7 kg |
| Noise Level |
36dB/34dB (Normal/Eco. Mode) |
| Power |
Supply: AC 100-240V, 50/60Hz Consumption: 350W (Eco. Mode), 430W (Normal Mode), <0.5W (Standby) |
| 3D Ready(DLP link, PC+Video) |
Yes |
| Remote Control P/N |
5041846600 |
| Standard Accessories |
VGA Cable, Warranty Card (by region), Remote Controller (with battery), AC Power Cord |
| Optional Accessories |
Remote Control P/N: 5041846600 |
| Warranty |
Large Venue Laser Phosphor Warranty: 5 Year projector / 5 years or 20.000h on the Laser Phosphor illumination source.(Whichever comes first) |
| UPC Code |
813097024138 |
